Markchem Krystol CW 100

KRYSTOL CW100 is a surface-applied, integral crystalline waterproofing material, which waterproofs and protects concrete in-depth. It consists of Portland cement, specially treated quartz sand and a compound of active chemicals. KRYSTOL CW100 needs only to be mixed with water prior to application. When applied to a concrete surface, the active chemicals react with moisture and the by-products of cement hydration to cause a catalytic reaction which generates an insoluble, crystalline structure. These crystals fill the pores and minor shrinkage cracks in the concrete to prevent any further water ingress (even under pressure). However, KRYSTOL CW100 will still allow the passage of vapor through the structure (i.e. the concrete will be able to “breathe”). Even after the concrete has cured, KRYSTOL CW100 remains dormant in the concrete and will reactivate in the presence of moisture to seal capillary tracts and hairline cracks. In addition to waterproofing the structure, KRYSTOL CW100 protects concrete against seawater, wastewater, aggressive ground water and many other aggressive chemical solutions. KRYSTOL CW100 is approved for use in contact with potable water, and is therefore suitable for use in water storage tanks, reservoirs, water treatment plants, etc.

  • Features / Advantages
  • Applications
  • Becomes an integral part of the concrete, forming a complete body of strength and durability
  • Penetrates deeply and seals concrete’s capillary tracts and shrinkage cracks
  • Can be applied from either the positive or negative side
  • Waterproofing and chemical-resistance properties remain intact even if the surface is damaged
  • Completely effective against high hydrostatic pressure
  • Easy to apply, labor-cost effective
  • Increases concrete’s compressive strength
  • Can be applied to moist or “green” concrete
  • Protects embedded steel (reinforcing steel and wire mesh)
  • Non-toxic. Approved for potable drinking water applications (NSF 61)
  • Zero VOC – KRYSTOL CW10 powdered products contain zero volatile organic compounds and are safe
  • for use both outdoors and in confined indoor spaces
  • Basement retaining walls
  • Parking structures
  • Concrete slabs (floor/roof/balcony, etc.)
  • Tunnels and subway systems
  • Construction joints
  • Water retaining structures
  • Underground vaults
  • Swimming pools
  • Sewage and water treatment plants
  • Channels
  • Drinking Water Reservoirs
  • Bridges, dams and roads
